Product Overview
Field Attachable Plastic Connector
Aptiv Interconnect Micro, formerly known as Ulti-Mate Connector, offers Nano Field Attachable Dual Row Metal Shell Connectors — a durable and compact solution for precision cable connections. These connectors feature a metal shell with flat leads, providing excellent shielding and mechanical protection. With an operating temperature range of −55°C to 125°C and high-temperature versions available up to 200°C (add HT), they are built to perform in harsh environments. Available in 9 to 65 contact configurations, these connectors are QPL qualified to MIL-DTL-32139, ensuring military-grade reliability and consistency.
Features and Benefits
- Field-Attachable, Inline Design: Simplifies installation and repairs without requiring factory assembly.
- Nano Circular Form Factor: Compact, lightweight solution ideal for tight-space and portable systems.
- Wide Temperature Range: Operates from −55°C to +125°C, ensuring reliable performance across diverse environments.
- High-Temperature (HT) Version: Supports operation up to 200°C for extreme thermal applications.
- Gold-Plated Contacts: Delivers excellent conductivity and long-term corrosion resistance.
- Durable Materials: Beryllium Copper and Brass provide robust mechanical and electrical performance.
- High-Performance Insulators: LCP or PPS materials rated to MIL-M-24519 for superior heat and chemical resistance.
- Contact Configuration: Supports multi-signal connectivity in a compact package.
