Product Overview

Solderable Connectors

Aptiv Interconnect Micro, formerly known as Ulti-Mate Connector, offers Micro Circular Solderable Connectors designed for high reliability in demanding environments. These inline circular plastic connectors feature soldercup contacts and perform across a wide temperature range from −55°C to 200°C, ensuring consistent performance in harsh conditions. Available in sizes 5, 7, 9, 12, and 16, these connectors deliver precision and durability across diverse applications.

Request Quote
Download Datasheet
Solderable Connectors product image

Features and Benefits

  • Wide Temperature Range: Operates reliably from −55°C to 200°C for use in extreme environments.
  • High-Quality Contacts: Signal Pin Contacts made from C17200 Beryllium Copper per ASTM B194 for strength and conductivity.
  • Durable Socket Contacts: Signal Socket Contacts crafted from C21000 Brass Alloy per ASTM B36 for long-lasting performance.
  • Gold-Plated Finish: Contact Plating per ASTM B488 ensures corrosion resistance and excellent conductivity.
  • Rugged Insulator Options: Available in LCP (GLCP-30F) or PPS per MIL-M-24519 GST-40F for enhanced durability.
  • Versatile Sizing: Offered in 5, 7, 9, 12, and 16 positions to suit varied design needs.

Specifications, Parts, and Filters

View All

Contact Resistance
8 milliohm max contact only and 32 millohms max with 6" length @ 2.5A.
Current Rating
3A max
Dielectric WithStanding Voltage
600 VAC at sea level, 150 VAC at 70,000 feet. 1mA leakage current max
Insulation Resistance
500 VDC and 5000 Megohms min for low temp products and 500VDC and 1000 Megohms min for high temp products

Engaging Force
6 oz max. (Signal contacts only, no data for Power or Coax contacts)
Separation Force
.5 oz. min. (Signal contacts only, no data for Power or Coax contacts)
Mating/Unmating Force
10 oz x # of contacts max. (Signal contacts only, no data for Power or Coax contacts)
Vibration
EIA-364-28 Condition IV, 1 microsecond max discontinuity
Shock
EIA-364-27 Condition E, 1 microsecond max discontinuity
Durability
500 matings, passes Mating Force, CR, Eng and Sep Forces
Salt Spray
EIA 364-26 Condition B-48 hours

Signal Pin Contacts
C17200 Beryllium Copper per ASTM B194
Signal Socket Contacts
C21000 Brass Alloy per ASTM B36
Contact Plating
Gold Plating per ASTM B488
Insulator Material
LCP(Liquid Crystal Polymer) GLCP-30F or PPS per MIL-M-24519 GST-40F
