Product Overview
Wired Standard Profile Metal Shell Connector
Aptiv Interconnect Micro offers Wired Standard Profile Metal Shell Connectors, engineered for durability and reliability in demanding environments. These Metal Shell Micro-D Combo Connectors support up to 10 coax or 65 signal positions and operate across a wide temperature range from −55°C to 200°C. Designed for applications requiring robust performance, they deliver consistent engagement, separation, and mating forces under extreme conditions. Tested for vibration, shock, and corrosion resistance, they ensure lasting performance in mission-critical systems.
Features and Benefits
- Versatile Configurations: Supports up to 10 coax or 65 signal positions.
- Wide Temperature Range: Operates from -55°C to 200°C for high-stress environments.
- Reliable Mechanical Performance: 6 oz max engaging force, 0.5 oz min separation force, and 10 oz × number of contacts max mating/unmating force (signal contacts only).
- Tested for Durability: Qualified per EIA-364-28 (vibration), EIA-364-27 (shock), and EIA 364-26 (salt spray).
- Long Mating Life: Proven endurance through 500 mating cycles while maintaining contact integrity.
Specifications, Parts, and Filters
Similar Products
Find the Right Product for the Design
Access robust technical resources and expert engineering support to create interconnect solutions designed for demanding environments. From standard components to fully customized designs, we support every stage of the development process.
