Product Overview
Wired Standard Profile Plastic Shell Connectors
Aptiv Interconnect Micro offers Wired Standard Profile Plastic Shell Connectors, designed for versatility and reliable performance across a wide temperature range. These Micro-D Combo connectors support up to 10 coax or 65 signal positions, making them ideal for applications requiring both signal and power connections. Standard models operate from −55°C to 125°C, with high-temperature versions available up to 200°C (add HT) for extreme conditions. Built with precision materials, they deliver consistent electrical performance and mechanical strength.
Features and Benefits
- Versatile Configurations: Supports up to 10 coax or 65 signal positions.
- Wide Operating Range: Standard models rated for −55°C to 125°C; high-temp versions up to 200°C.
- Durable Contact Materials: Signal pins (C17200 Beryllium Copper), signal sockets (C21000 Brass Alloy), power pins (C3600 Brass), power sockets (C17300 Beryllium Copper), coax centers (C21000 Brass Alloy).
- Reliable Electrical Performance: Engineered for consistent conductivity and low resistance.
- Customizable Solutions: Configurable to meet unique project or environmental requirements.
Specifications, Parts, and Filters
Similar Products
Find the Right Product for the Design
Access robust technical resources and expert engineering support to create interconnect solutions designed for demanding environments. From standard components to fully customized designs, we support every stage of the development process.
