Vertical Dual Row Plated Thru Hole Metal Shell (Style 6) Connector
Aptiv Interconnect Micro offers Nano PCB Vertical Dual Row Plated Thru Hole Metal Shell (Style 6) Connectors, engineered for dependable performance and long-term reliability. Featuring a metal shell with surface mount .050 x .050 configuration, these connectors include a 1-piece contact with flat tail termination for secure soldering and mechanical strength. Operating efficiently from −55°C to 125°C, with high-temperature versions available up to 200°C (add HT), they are ideal for demanding environments.
Features and Benefits
- Rugged Metal Shell Design: Ensures durability and reliable EMI protection.
- Piece Contact Construction: Provides consistent electrical performance and secure termination.
- Wide Temperature Range: Operates from −55°C to 125°C; HT versions up to 200°C.
- Excellent Mechanical Strength: 5 oz max engaging force, 0.4 oz min separation force, and 7 oz × number of contacts mating/unmating force.
- High Shock and Vibration Resistance: Tested per EIA-364-28 (vibration) and EIA-364-27 (shock), 1 µs max discontinuity.
- Flexible Configurations: Available with 9 to 65 contacts.
- Qualified Performance: QPL approved for MIL-DTL-32139 compliance.
- Ideal for High-Reliability PCB Applications: Perfect for aerospace, defense, and instrumentation systems.
Specifications, Parts, and Filters
C_Dimensional.webp)
| 2D DIMENSIONAL DATA - NANO CIRCUIT DUAL ROW | |||||
|---|---|---|---|---|---|
| Size | A | B |
Plug
C
|
Receptacle | D |
| 9 | .375 [9.52] | .270 [6.86] | .160 [4.06] | .163 [4.14] | .175 [4.44] |
| 15 | .450 [11.43] | .345 [8.76] | .235 [5.97] | .238 [6.04] | .250 [6.35] |
| 21 | .525 [13.33] | .420 [10.67] | .310 [7.87] | .313 [7.95] | .325 [8.25] |
| 25 | .575 [14.60] | .470 [11.94] | .360 [9.14] | .363 [9.22] | .375 [9.52] |
| 31 | .650 [16.51] | .545 [13.84] | .435 [11.05] | .438 [11.12] | .450 [11.43] |
| 37 | .725 [18.41] | .620 [15.75] | .510 [12.95] | .513 [13.03] | .525 [13.33] |
| 51 | .900 [22.86] | .795 [20.19] | .685 [17.40] | .688 [17.47] | .700 [17.78] |
| 65 | 1.075 [27.30] | .970 [24.64] | .860 [21.84] | .863 [21.92] | .875 [22.22] |
| Nano-D Right Angle Dual Row Plated Thru Hole Metal Shell | ||||||
|---|---|---|---|---|---|---|
| Size | Gender | Eng# | Ordering# | 2D | 3D | PCB |
| 9 | ||||||
| Male | CNM6L09-2P071-S01 | 832311617 | 2D | 3D | PCB | |
| Female | CNM6L09-2S071-S01 | 832411617 | 2D | 3D | PCB | |
| 15 | ||||||
| Male | CNM6L15-2P071-S01 | 832321617 | 2D | 3D | PCB | |
| Female | CNM6L15-2S071-S01 | 832421617 | 2D | 3D | PCB | |
| 21 | ||||||
| Male | CNM6L21-2P071-S01 | 832331617 | 2D | 3D | PCB | |
| Female | CNM6L21-2S071-S01 | 832431617 | 2D | 3D | PCB | |
| 25 | ||||||
| Male | CNM6L25-2P071-S01 | 832341617 | 2D | 3D | PCB | |
| Female | CNM6L25-2S071-S01 | 832441617 | 2D | 3D | PCB | |
| 31 | ||||||
| Male | CNM6L31-2P071-S01 | 832351617 | 2D | 3D | PCB | |
| Female | CNM6L31-2S071-S01 | 832451617 | 2D | 3D | PCB | |
| 37 | ||||||
| Male | CNM6L37-2P071-S01 | 832361617 | 2D | 3D | PCB | |
| Female | CNM6L37-2S071-S01 | 832461617 | 2D | 3D | PCB | |
| 51 | ||||||
| Male | CNM6L51-2P071-S01 | 832371617 | 2D | 3D | PCB | |
| Female | CNM6L51-2S071-S01 | 832471617 | 2D | 3D | PCB | |
| 65 | ||||||
| Male | CNM6L65-2P071-S01 | 832381617 | 2D | 3D | PCB | |
| Female | CNM6L65-2S071-S01 | 832481617 | 2D | 3D | PCB | |
Part Number: 432411627
Engineering Part Number: CNM6L09-2S072-S01 HT
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 9, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Gold Plated, PC Tail Length: 0.109, Plating Type: Nickel, Shell Material: Metal, Max Temp: 200 C, QPL: No
Part Number: 432421627
Engineering Part Number: CNM6L15-2S072-S01 HT
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 15, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Gold Plated, PC Tail Length: 0.109, Plating Type: Nickel, Shell Material: Metal, Max Temp: 200 C, QPL: No
Part Number: 432431627
Engineering Part Number: CNM6L21-2S072-S01 HT
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 21, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Gold Plated, PC Tail Length: 0.109, Plating Type: Nickel, Shell Material: Metal, Max Temp: 200 C, QPL: No
Part Number: 432441627
Engineering Part Number: CNM6L25-2S072-S01 HT
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 25, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Gold Plated, PC Tail Length: 0.109, Plating Type: Nickel, Shell Material: Metal, Max Temp: 200 C, QPL: No
Part Number: 432451627
Engineering Part Number: CNM6L31-2S072-S01 HT
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 31, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Gold Plated, PC Tail Length: 0.109, Plating Type: Nickel, Shell Material: Metal, Max Temp: 200 C, QPL: No
Part Number: 432461627
Engineering Part Number: CNM6L37-2S072-S01 HT
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 37, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Gold Plated, PC Tail Length: 0.109, Plating Type: Nickel, Shell Material: Metal, Max Temp: 200 C, QPL: No
Part Number: 432471627
Engineering Part Number: CNM6L51-2S072-S01 HT
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 51, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Gold Plated, PC Tail Length: 0.109, Plating Type: Nickel, Shell Material: Metal, Max Temp: 200 C, QPL: No
Part Number: 432481627
Engineering Part Number: CNM6L65-2S072-S01 HT
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 65, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Gold Plated, PC Tail Length: 0.109, Plating Type: Nickel, Shell Material: Metal, Max Temp: 200 C, QPL: No
Part Number: 832311617
Engineering Part Number: CNM6L092P071-S01
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 9, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Plating Type: Nickel, Shell Material: Metal, Max Temp: 125 C, QPL: No
Part Number: 832321617
Engineering Part Number: CNM6L15-2P071-S01
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 15, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Plating Type: Nickel, Shell Material: Metal, Max Temp: 125 C, QPL: No
