Vertical Dual Row Plated Thru Hole Plastic Shell (Style 6) Connector
Aptiv Interconnect Micro offers Nano PCB Vertical Dual Row Plated Thru Hole Plastic Shell (Style 6) Connectors, designed for compact, high-performance PCB applications. Featuring a plastic shell with plated thru-hole .050 x .050 (Style 6) configuration, these connectors include a 1-piece contact and flat tail termination for strong, reliable solder connections. They operate across a −55°C to 125°C temperature range, with high-temperature versions available up to 200°C (add HT), ensuring dependable performance in demanding environments. .
Features and Benefits
- Lightweight Plastic Shell: Provides strength and weight reduction for compact designs.
- Piece Contact with Flat Tail: Delivers stable electrical performance and secure solder joints.
- Wide Temperature Range: Standard operation from −55°C to 125°C; HT versions up to 200°C.
- Flexible Configurations: Available with 9 to 65 contacts for various design needs.
- QPL Qualified: Meets MIL-DTL-32139 military performance standards.
- Ideal for Space-Sensitive PCB Applications: Perfect for aerospace, medical, and instrumentation systems requiring precision and reliability.
Specifications, Parts, and Filters
C_Dimensional.webp)
| 2D DIMENSIONAL DATA - NANO CIRCUIT DUAL ROW | |||||
|---|---|---|---|---|---|
| Size | A | B |
Plug
C
|
Receptacle | D |
| 9 | .375 [9.52] | .270 [6.86] | .160 [4.06] | .163 [4.14] | .175 [4.44] |
| 15 | .450 [11.43] | .345 [8.76] | .235 [5.97] | .238 [6.04] | .250 [6.35] |
| 21 | .525 [13.33] | .420 [10.67] | .310 [7.87] | .313 [7.95] | .325 [8.25] |
| 25 | .575 [14.60] | .470 [11.94] | .360 [9.14] | .363 [9.22] | .375 [9.52] |
| 31 | .650 [16.51] | .545 [13.84] | .435 [11.05] | .438 [11.12] | .450 [11.43] |
| 37 | .725 [18.41] | .620 [15.75] | .510 [12.95] | .513 [13.03] | .525 [13.33] |
| 51 | .900 [22.86] | .795 [20.19] | .685 [17.40] | .688 [17.47] | .700 [17.78] |
| 65 | 1.075 [27.30] | .970 [24.64] | .860 [21.84] | .863 [21.92] | .875 [22.22] |
| Nano-D Vertical Dual Row Plated Thru Hole Plastic Shell | ||||
|---|---|---|---|---|
| Size | Gender | Eng# | Ordering# | PCB |
| 9 | ||||
| Male | CNP6L09-2P071 | 832318617 | PCB | |
| Female | CNP6L09-2S071 | 832418617 | PCB | |
| 15 | ||||
| Male | CNP6L15-2P071 | 832328617 | PCB | |
| Female | CNP6L15-2S071 | 832428617 | PCB | |
| 21 | ||||
| Male | CNP6L21-2P071 | 832338617 | PCB | |
| Female | CNP6L21-2S071 | 832438617 | PCB | |
| 25 | ||||
| Male | CNP6L25-2P071 | 832348617 | PCB | |
| Female | CNP6L25-2S071 | 832448617 | PCB | |
| 31 | ||||
| Male | CNP6L31-2P071 | 832358617 | PCB | |
| Female | CNP6L31-2S071 | 832458617 | PCB | |
| 37 | ||||
| Male | CNP6L37-2P071 | 832368617 | PCB | |
| Female | CNP6L37-2S071 | 832468617 | PCB | |
| 51 | ||||
| Male | CNP6L51-2P071 | 832378617 | PCB | |
| Female | CNP6L51-2S071 | 832478617 | PCB | |
| 65 | ||||
| Male | CNP6L65-2P071 | 832388617 | PCB | |
| Female | CNP6L65-2S071 | 832488617 | PCB | |
Part Number: 832318617
Engineering Part Number: CNP6L092P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 9, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832328617
Engineering Part Number: CNP6L152P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 15, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832338617
Engineering Part Number: CNP6L212P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 21, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832348617
Engineering Part Number: CNP6L252P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 25, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832358617
Engineering Part Number: CNP6L312P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 31, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832368617
Engineering Part Number: CNP6L37-2P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 37, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832378617
Engineering Part Number: CNP6L512P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 51, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832388617
Engineering Part Number: CNP6L652P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 65, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832418617
Engineering Part Number: CNP6L09-2S071
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 9, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832428617
Engineering Part Number: CNP6L15-2S071
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 15, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: Thru-Hole, Thru-Hole PCB Layout: .050 x .050 (style 6), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
