Vertical Dual Row Surface Mount Plastic Shell (Style 26) Connector
Aptiv Interconnect Micro, formerly known as Ulti-Mate Connector, offers Nano PCB Vertical Dual Row Surface Mount Metal Shell (Style 26) Connectors, engineered for exceptional reliability and performance in demanding applications. These connectors feature a metal shell with surface mount .025 x .075 (Style 26) configuration and a rectangular flat tail design that ensures superior soldering results with no lead deformation. Operating across a −55°C to 125°C temperature range, with high-temperature versions available up to 200°C (add HT), these connectors are ideal for rugged environments where consistent electrical performance is essential.
Features and Benefits
- Durable Plastic Shell Design: Lightweight and reliable for diverse PCB applications.
- Rectangular Flat Tail Configuration: Ensures distortion-free soldering and precise board mounting.
- Wide Temperature Range: Operates from −55°C to 125°C; HT versions extend to 200°C.
- High-Quality Materials: Signal Pin & Socket Contacts
- Available in 9 to 65 Contacts: Suitable for multiple configurations and high-density designs.
- Ideal for Compact and Precision PCB Applications: Perfect for use in aerospace, defense, and instrumentation systems requiring reliable Nano-D connectivity.
Specifications, Parts, and Filters
C_Dimensional.webp)
| 2D DIMENSIONAL DATA - NANO CIRCUIT DUAL ROW | |||||
|---|---|---|---|---|---|
| Size | A | B |
Plug
C
|
Receptacle | D |
| 9 | .375 [9.52] | .270 [6.86] | .160 [4.06] | .163 [4.14] | .175 [4.44] |
| 15 | .450 [11.43] | .345 [8.76] | .235 [5.97] | .238 [6.04] | .250 [6.35] |
| 21 | .525 [13.33] | .420 [10.67] | .310 [7.87] | .313 [7.95] | .325 [8.25] |
| 25 | .575 [14.60] | .470 [11.94] | .360 [9.14] | .363 [9.22] | .375 [9.52] |
| 31 | .650 [16.51] | .545 [13.84] | .435 [11.05] | .438 [11.12] | .450 [11.43] |
| 37 | .725 [18.41] | .620 [15.75] | .510 [12.95] | .513 [13.03] | .525 [13.33] |
| 51 | .900 [22.86] | .795 [20.19] | .685 [17.40] | .688 [17.47] | .700 [17.78] |
| 65 | 1.075 [27.30] | .970 [24.64] | .860 [21.84] | .863 [21.92] | .875 [22.22] |
| Nano Series Circuit Dual Row Vertical Surface Mount Plastic Shell | |||||
|---|---|---|---|---|---|
| Size | Gender | Eng# | Ordering# | 2D | PCB |
| 9 | |||||
| Male | CNP26L09-2P071 | 832318317 | 2D | PCB | |
| Female | CNP26L09-2S071 | 832418317 | 2D | PCB | |
| 15 | |||||
| Male | CNP26L15-2P071 | 832328317 | 2D | PCB | |
| Female | CNP26L15-2S071 | 832428317 | 2D | PCB | |
| 21 | |||||
| Male | CNP26L21-2P071 | 832338317 | 2D | PCB | |
| Female | CNP26L21-2S071 | 832438317 | 2D | PCB | |
| 25 | |||||
| Male | CNP26L25-2P071 | 832348317 | 2D | PCB | |
| Female | CNP26L25-2S071 | 832448317 | 2D | PCB | |
| 31 | |||||
| Male | CNP26L31-2P071 | 832358317 | 2D | PCB | |
| Female | CNP26L31-2S071 | 832458317 | 2D | PCB | |
| 37 | |||||
| Male | CNP26L37-2P071 | 832368317 | 2D | PCB | |
| Female | CNP26L37-2S071 | 832468317 | 2D | PCB | |
| 51 | |||||
| Male | CNP26L51-2P071 | 832378317 | 2D | PCB | |
| Female | CNP26L51-2S071 | 832478317 | 2D | PCB | |
| 65 | |||||
| Male | CNP26L65-2P071 | 832388317 | 2D | PCB | |
| Female | CNP26L65-2S071 | 832488317 | 2D | PCB | |
Part Number: 832318317
Engineering Part Number: CNP26L09-2P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 9, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: SMT, Thru-Hole PCB Layout: .025 x .075 (style 26), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832328317
Engineering Part Number: CNP26L15-2P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 15, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: SMT, Thru-Hole PCB Layout: .025 x .075 (style 26), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832338317
Engineering Part Number: CNP26L21-2P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 21, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: SMT, Thru-Hole PCB Layout: .025 x .075 (style 26), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832348317
Engineering Part Number: CNP26L25-2P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 25, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: SMT, Thru-Hole PCB Layout: .025 x .075 (style 26), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832358317
Engineering Part Number: CNP26L31-2P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 31, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: SMT, Thru-Hole PCB Layout: .025 x .075 (style 26), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832368317
Engineering Part Number: CNP26L37-2P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 37, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: SMT, Thru-Hole PCB Layout: .025 x .075 (style 26), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832378317
Engineering Part Number: CNP26L51-2P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 51, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: SMT, Thru-Hole PCB Layout: .025 x .075 (style 26), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832388317
Engineering Part Number: CNP26L65-2P071
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 65, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: SMT, Thru-Hole PCB Layout: .025 x .075 (style 26), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832418312
Engineering Part Number: CNP26L09-2S021
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 9, Hardware: Allen Head Jackscrew, Number of Rows: 2, PCB Termination: SMT, Thru-Hole PCB Layout: .025 x .075 (style 26), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
Part Number: 832418317
Engineering Part Number: CNP26L09-2S071
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 9, Hardware: Threaded Hole, Number of Rows: 2, PCB Termination: SMT, Thru-Hole PCB Layout: .025 x .075 (style 26), Orientation: Vertical, Lead Finish: Tin Lead, Shell Material: Plastic, Max Temp: 125 C, QPL: No
