Product Overview
Single Row Series Connector
Aptiv Interconnect Micro offers Nano Strip Single Row Series Connectors, precision engineered for high-density, lightweight interconnect applications. Featuring a durable plastic strip and wire leads, these connectors perform reliably across extreme temperature ranges from -55°C to 125°C, and even up to 200°C with the high-temperature (HT) option. As a QPL-qualified supplier for MIL-DTL-32139 products, Aptiv ensures military-grade quality and performance for critical systems requiring miniature, robust connectivity.
Features and Benefits
- Field-Attachable, Inline Design: Simplifies installation and repairs without requiring factory assembly.
- Nano Circular Form Factor: Compact, lightweight solution ideal for tight-space and portable systems.
- Wide Temperature Range: Operates from −55°C to +125°C, ensuring reliable performance across diverse environments.
- High-Temperature (HT) Version: Supports operation up to 200°C for extreme thermal applications.
- Gold-Plated Contacts: Delivers excellent conductivity and long-term corrosion resistance.
- Durable Materials: Beryllium Copper and Brass provide robust mechanical and electrical performance.
- High-Performance Insulators: LCP or PPS materials rated to MIL-M-24519 for superior heat and chemical resistance.
- Contact Configuration: Supports multi-signal connectivity in a compact package.
Specifications, Parts, and Filters
Part Number: 437065020
Engineering Part Number: NSR06P0-L05-HT
Termination: PCB, Contact Gender: Pin, Number of signal contacts: 6, Hardware: No Hardware, PCB Termination: SMT, Orientation: Right Angle, Shell Material: Plastic, Max Temp: 200 C
Part Number: 437135451
Engineering Part Number: NSR-13P1-30F6-18.0 HT
Termination: Wired, Contact Gender: Pin, Number of signal contacts: 13, Hardware: One guide post (post on socket side), Wire AWG: 30, Wire Type: Stranded w/ Teflon insulation (NEMA HP3-ET), Wire Color: 10 Repeating Colors, Wire Length: 18 in., Shell Material: Plastic, Max Temp: 200 C
Part Number: 837025903
Engineering Part Number: NSR-02P0-32F1-18.0
Termination: Wired, Contact Gender: Pin, Number of signal contacts: 2, Hardware: No Hardware, Wire AWG: 32, Wire Type: Stranded w/ Teflon insulation (NEMA HP3-ET), Wire Color: White, Wire Length: 18 in., Shell Material: Plastic, Max Temp: 125 C
Part Number: 837026020
Engineering Part Number: NSR-02S0-L05
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 2, Hardware: No Hardware, PCB Termination: SMT, Orientation: Right Angle, Shell Material: Plastic, Max Temp: 125 C
Part Number: 837026101
Engineering Part Number: NSR-02S1-32E5-18.0
Termination: Wired, Contact Gender: Socket, Number of signal contacts: 2, Hardware: One guide post (post on socket side), Wire AWG: 32, Wire Type: Stranded w/ Teflon insulation (NEMA HP3-EX), Wire Color: Non-Repeating Colors (Mil-Std-681), Wire Length: 18 in., Shell Material: Plastic, Max Temp: 125 C
Part Number: 837026120
Engineering Part Number: NSR-02S1-L05
Termination: PCB, Contact Gender: Socket, Number of signal contacts: 2, Hardware: One guide post (post on socket side), PCB Termination: SMT, Orientation: Right Angle, Shell Material: Plastic, Max Temp: 125 C
Part Number: 837026460
Engineering Part Number: NSR02S0-32F1-18.0
Termination: Wired, Contact Gender: Socket, Number of signal contacts: 2, Hardware: No Hardware, Wire AWG: 32, Wire Type: Stranded w/ Teflon insulation (NEMA HP3-ET), Wire Color: White, Wire Length: 18 in., Shell Material: Plastic, Max Temp: 125 C
Part Number: 837035100
Engineering Part Number: NSR-03P0-32E5-18.0
Termination: Wired, Contact Gender: Pin, Number of signal contacts: 3, Hardware: No Hardware, Wire AWG: 32, Wire Type: Stranded w/ Teflon insulation (NEMA HP3-EX), Wire Color: Non-Repeating Colors (Mil-Std-681), Wire Length: 18 in., Shell Material: Plastic, Max Temp: 125 C
Part Number: 837035451
Engineering Part Number: NSR-03P1-30F6-18.0
Termination: Wired, Contact Gender: Pin, Number of signal contacts: 3, Hardware: One guide post (post on socket side), Wire AWG: 30, Wire Type: Stranded w/ Teflon insulation (NEMA HP3-ET), Wire Color: 10 Repeating Colors, Wire Length: 18 in., Shell Material: Plastic, Max Temp: 125 C
Part Number: 837035900
Engineering Part Number: NSR-03P0-36F6-18.0
Termination: Wired, Contact Gender: Pin, Number of signal contacts: 3, Hardware: No Hardware, Wire AWG: 36, Wire Type: Stranded w/ Teflon insulation (NEMA HP3-ET), Wire Color: 10 Repeating Colors, Wire Length: 18 in., Shell Material: Plastic, Max Temp: 125 C
