Wired Dual Row Double Ended Plastic Shell Connector

Aptiv Interconnect Micro offers Nano Wired Dual Row Double Ended Plastic Shell Connectors, engineered for high performance and reliability in demanding environments. These plastic shell connectors with wire leads operate across a temperature range of −55°C to 125°C, with high-temperature versions available up to 200°C (add HT). Available in 9 to 65 contacts, they deliver excellent electrical performance with a contact resistance of 33 milliohms max (contact only) and 87 milliohms max with 6" wire at 1A. They feature a current rating of 1A max and dielectric withstanding voltages of 250 VAC at sea level and 100 VAC at 70,000 feet, with a 1mA leakage current maximum.
