Wired Single Row Single Ended Connector

Aptiv Interconnect Micro, formerly known as Ulti-Mate Connector, offers Nano Wired Single Row Single Ended Connectors designed for precision, durability, and superior performance. These metal shell connectors with wire leads operate from −55°C to 125°C, with high-temperature versions up to 200°C (add HT) for extreme conditions. Available in 9 to 51 contacts, they ensure reliable performance in compact and demanding applications. As a QPL qualified supplier for MIL-DTL-32139 products, Aptiv guarantees consistent quality and long-term dependability.

Request Quote
Download Datasheet
Wired Single Row Single Ended Connector product image

Features and Benefits

  • Single Row Design: Compact and efficient layout suited for high-density applications.
  • Metal Shell Construction: Ensures robust mechanical strength and shielding protection.
  • Wide Temperature Range: Operates from −55°C to 125°C, extendable up to 200°C (HT option).
  • Reliable Electrical Performance: Maximum contact resistance of 33 milliohms (contact only) and 87 milliohms with 6" wire at 1A.
  • Dielectric Strength: Withstands 250 VAC at sea level and 100 VAC at 70,000 feet for insulation integrity.
  • Qualified to MIL-DTL-32139: Ensures military-grade quality and proven reliability.
  • Flexible Contact Options: Available with 9 to 51 contacts to meet diverse interconnect needs.

Specifications, Parts, and Filters

View All

Contact Resistance
33 milliohm max contact only and 87 milliohms max with 6" wire @ 1A
Current Rating
1A max.
Dielectric WithStanding Voltage
250 VAC at sea level, 100 VAC at 70,000 feet. 1mA leakage current max.
Insulation Resistance
100 VDC and 5000 Megohms min.

Engaging Force
5 oz max.
Separation Force
.4 oz min.
Mating/Unmating Force
7 oz x # of contacts max.
Vibration
EIA-364-28 Condition IV, 1 microsecond max discontinuity
Shock
EIA-364-27 Condition G, 1 microsecond max discontinuity
Durability
EIA-364-09, 200 matings, passes Mating Force, CR, Eng and Sep Forces
Salt Spray
EIA 364-26 Condition B-48 hours

Signal Pin Contacts
C17410 Beryllium Copper per ASTM B768
Signal Socket Contacts
C17410 Beryllium Copper per ASTM B768
Contact Plating
Gold Plating per ASTM B488
PC Tails
C17410 Beryllium Copper per ASTM B768
PC Tail Plating
60/40 Tin/Lead plating per SAE-AMS-P-81728, or Gold plating per ASTM B488
Insulator Material
LCP(Liquid Crystal Polymer) GLCP-30F or PPS per MIL-M-24519 GST-40F
