3.5mm Series RF Connector

The Aptiv Interconnect 3.5mm RF connector is a high-performance precision coaxial connector for microwave applications up to 34.5 GHz. As an improvement over the standard SMA, it features a more robust mechanical interface with a thickened outer conductor wall and an air dielectric, enhancing durability and electrical performance. The 3.5mm connector's female contact is supported by a dielectric bead, preventing "springing" for more reliable connections. Crucially, it is fully intermateable with SMA connectors, making it an excellent upgrade path for existing systems. It is widely used in test and measurement, telecommunications, satellite communication, and high-frequency instrumentation.

Request Quote
Download Datasheet
3.5mm Series RF Connector product image

Features and Benefits

  • Extended Frequency Range: Operates up to 34.5 GHz, outperforming standard SMA connectors.
  • Intermateability with SMA: Connects directly with SMA devices without adapters.
  • Robust Mechanical Design: Thicker outer wall and reinforced female contact for enhanced durability.
  • Precision Threaded Coupling: Ensures a secure, stable, and vibration-resistant connection.
  • Excellent Electrical Performance: Low VSWR and insertion loss due to precision manufacturing.
  • 50 Ohm Impedance: Standardized for broad system compatibility.
  • High Reliability: Designed for consistent performance over many mating cycles.
  • Versatile Applications: Ideal for high-speed data, aerospace, defense, and more.

Specifications, Parts, and Filters

View All

Impedance
50 Ohms
Frequency Range
DC to 34.5 GHz
Voltage Rating
Typically 335 VRMS (max. typical)
Dielectric Withstanding Voltage
1000 VRMS (min. typical)
Contact Resistance
Center Contact
≤ 3.0 mΩ (typical)
Outer Contact
≤ 2.0 mΩ (typical)
VSWR (Voltage Standing Wave Ratio)
Typical
≤ 1.25 @ 34.5 GHz
Insertion Loss
≤ 0.05 * f(GHz)​ dB (typical)

Coupling Mechanism
Threaded
Mating Cycles
≥ 500 cycles
Recommended Mating Torque
7 - 10 in-lbs (0.9 - 1.1 Nm)
Cable Retention
Varies by cable type and termination method
Body Material
Stainless Steel or Passivated Stainless Steel
Center Contact Material
Beryllium Copper with Gold Plating
Outer Contact Material
Stainless Steel or Brass
Dielectric/Insulator Material
Air/Low-loss plastic beads
Interface Dimensions
Conforms to IEEE Std 287 Type 3.5mm, and MIL-STD-348.

Temperature Range
-65°C to +165°C
Thermal Shock
MIL-STD-202, Method 107, Test Condition B
Vibration
MIL-STD-202, Method 204, Test Condition D
Shock
MIL-STD-202, Method 213, Test Condition I
Moisture Resistance
MIL-STD-202, Method 106
Corrosion (Salt Fog)
MIL-STD-202, Method 101, Test Condition B
Altitude
MIL-STD-202, Method 105, Test Condition C
